Create Points Evolve Mechanical Help Places points within the current view with a variety of placement methods. the create points window lets users quickly define point’s and select the type and number of points to place. all points can be exported through the point manager feature as .tfl or .csv files. The evolve point layout feature allows you to do point layout drawings efficiently and export points to a csv or tfl file. you can quickly renumber points and add descriptions.
Nesting Points Evolve Mechanical Help This video demonstrates key features of evolve mep mechanical software, including optimizing ductwork fittings by merging straights, adjusting fitting tolerance, rotating components along x, y, and z axes, and creating various layout and control points for precise design and coordination. Help documentation for the evolve mechanical software, fabrication productivity tools for revit. Use true north checkbox when checked, points are exported based on the project's "true north" orientation. if unchecked, the angle specified in the origin option is used. The only fabrication part points that the point manager will recognize is from mep hangers. all other points you add to your project must be the evpoint. you can easily nest these points into any family you wish and they will show on the point manager.
Placing Points Evolve Mechanical Help Use true north checkbox when checked, points are exported based on the project's "true north" orientation. if unchecked, the angle specified in the origin option is used. The only fabrication part points that the point manager will recognize is from mep hangers. all other points you add to your project must be the evpoint. you can easily nest these points into any family you wish and they will show on the point manager. See how the latest version of evolve mechanical for revit can transform bim designs for mep systems!. From the point manager window, select the desired points from the grid, and click auto number from the tool palette. from the auto number window, type a value in the starting value dialog box and click ok. From the point placement panel, ensure the single point radio button is selected. from the drawing area (near the intended hosting element), click to place the newly created point in the project. From the evolve ribbon, in the points panel, click create points. from the create points window select the desired settings. click ok to begin creating points. in the drawing area, follow the status bar prompts to complete point creation.
Nesting Points Evolve Mechanical Help See how the latest version of evolve mechanical for revit can transform bim designs for mep systems!. From the point manager window, select the desired points from the grid, and click auto number from the tool palette. from the auto number window, type a value in the starting value dialog box and click ok. From the point placement panel, ensure the single point radio button is selected. from the drawing area (near the intended hosting element), click to place the newly created point in the project. From the evolve ribbon, in the points panel, click create points. from the create points window select the desired settings. click ok to begin creating points. in the drawing area, follow the status bar prompts to complete point creation.
Nesting Points Evolve Mechanical Help From the point placement panel, ensure the single point radio button is selected. from the drawing area (near the intended hosting element), click to place the newly created point in the project. From the evolve ribbon, in the points panel, click create points. from the create points window select the desired settings. click ok to begin creating points. in the drawing area, follow the status bar prompts to complete point creation.
