Ar15 Pivot Pin Tool Proâ â Real Avid How do you keep the little detent in place, under spring pressure, while you install the pivot pin? brownells gun tech steve ostrem shows us the easy way to get this job done using the. Now, instead of struggling with your spring and your detent, you drop the spring in, drop the detent in behind it, then you depress it with your 330 second inch punch till it goes below the surface of the tool and rotate the tool.
Effortless Front Takedown Pin Installation The Ar15 Pivot Pin Tool The m16 and many commercial clones of the ar 15 use a pivot pin se cured in the lower receiver by a spring loaded detent to join the upper and lower receiver assemblies. To use, simply insert the tool through the pivot pin bosses on the front of the lower, and line up the hole in the tool with the detent hole in the lower. now insert the spring, then the detent. depress the detent with a small punch until the detent is just completely inside the detent hole. Use the pivot pin depressor to compress the spring loaded detent to free the pivot pin for removal a truly frustrating chore made simple with this tool. works on all mil spec ar 15s, except those from colt mfg. The pivot pin installation tool helps prevent the loss of detents. it works by holding the detent and spring in place while also serving as a slave pin when installing the pivot pin.
Obsidian Arms Ar 15 Armorer S Pivot Pin Detent Tool Brownells Uk Use the pivot pin depressor to compress the spring loaded detent to free the pivot pin for removal a truly frustrating chore made simple with this tool. works on all mil spec ar 15s, except those from colt mfg. The pivot pin installation tool helps prevent the loss of detents. it works by holding the detent and spring in place while also serving as a slave pin when installing the pivot pin. I use a utility knife blade to hold the spring and detent pin in place while slipping the takedown pin over and into place. this works great if you don't have the install tool, or for some reason have to make the repair in the field. Just a quick tip vid for ar 15 and ar 10 pivot pin installs. Place the small metal detent on top of the detent spring. approxi mately half of the det nt will project out of the hole in the installation tool. a 3⁄32" diameter or smaller punch should be used to press the detent down into the detent spring hole far enough to permit 90°. Gently push the installation tool to guide the detent and spring into place. while maintaining pressure on the installation tool, insert the pivot pin into the hole.
