Sheet Metal Rectangular Tray Ourengineeringlabs The document provides instructions for making a rectangular tray from a sheet of galvanized iron. it details the necessary tools, steps for layout marking, shearing, folding, and finishing to produce the tray according to the given dimensions. Cut the given sheet with straight snips as required. fold the given sheet using a bending machine, bench vice, stakes and ball peen hammer to get the required shape. mark the centres where to join the corners by using the centre punch, and make the drill holes of 3.5mm diameter and do riveting.
Rectangular Tray Make Origami In this video, you’ll learn how to make a large rectangular metal tray from scratch.we go step by step — from cutting the steel sheet to bending, welding, an. Using steel rule and scriber draw five vertical lines at a distance of 10mm, 40mm, 160mm and 190mm from reference vertical edge. now in your work sheet you have four lines and five spaces. Aim: to make a rectangular tray, using the given sheet metal. tools: steel rule, try square, divider, scriber, straight snip, mallet, ball – peen hammer and hatchet stake. Remove the unwanted material by using a straight snip. fold the edges on the required sides by using a suitable stake. bend the sheet at required markings to get the shape using suitable stake and mallet. the rectangular tray of required dimensions is obtained.
Rectangular Tray Make Origami Aim: to make a rectangular tray, using the given sheet metal. tools: steel rule, try square, divider, scriber, straight snip, mallet, ball – peen hammer and hatchet stake. Remove the unwanted material by using a straight snip. fold the edges on the required sides by using a suitable stake. bend the sheet at required markings to get the shape using suitable stake and mallet. the rectangular tray of required dimensions is obtained. For this the development of the article is first drawn on the sheet metal, then cut and folded, to form the required shape of the article. allowance should be given in the drawing stage for folding and bending. If required smooth the edges using a metal file and emery paper. secure the sheet in a bench vice or use a folding bar for bending. bend the four edges upward along the 10 mm bending lines. Procedure: study the given drawing check the work piece by steel rule. marking the work piece as per the given drawing by using steel rule and scriber. cut the work piece as per the drawing by using snips. file four sides of the work piece and make it correct dimensions. If you are really enjoying sheet metal work and want to go a step further after you make a tool tray, try designing a full tool box for this tray to sit in! in the following steps i'm going to walk you through making this sheet metal tool tray.
